850nm 150m QSFP+ Optical Transceiver Arista XVR-10066-20 QSFP-40G-SRBD 40GBASE-SR BD
Product Details:
| Place of Origin: | Malaysia |
| Brand Name: | ARISTA |
| Model Number: | XVR-10066-20 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiate |
| Delivery Time: | 5-8天 |
| Payment Terms: | TT, PayPal |
|
Detail Information |
|||
| Connector Type: | QSFP+ | Data Rate: | 40Gbps |
|---|---|---|---|
| Wavelength: | 850nm | Distance: | 150m |
| Fiber Type: | MMF | Temperature Range: | 0℃~70℃ |
| High Light: | 850nm QSFP+ Optical Transceiver,BD 40g QSFP+ Transceiver,BD QSFP+ Optical Transceiver |
||
Product Description
Arista XVR-10066-20 QSFP-40G-SRBD 40GBASE-SR BD 850nm 150m QSFP+ Optical Transceiver
Arista QSFP-40G-SRBD 40GBASE-SR BD QSFP+ 850nm 150m LC DOM Transceiver Module XVR-10066-20
The Arista QSFP-40G-SRBD is designed for use in 40 Gigabit Ethernet (40GE) applications over duplex multimode fiber. It is a high-performance 40GBASE-SR-BiDi QSFP+ optical Transceiver for 40G short-range duplex data communication and interconnects applications. This 40G transceiver operates on the wavelength of 832nm to 918nm via an LC connector and supports link lengths of 100m on OM3 multimode fiber or 150m on OM4 multimode fiber.
Features
- Compliant to the 40GbE XLPPI electrical specification per IEEE 802.3ba-2010
- Compliant to QSFP+ SFF-8436 Specification
- Aggregate bandwidth of 40Gbps
- Operates at 10.3125 Gbps per electrical channel with 64b/66b encoded data
- QSFP MSA compliant
- Utilizes a standard LC duplex fiber cable allowing reuse of existing cable infrastructure
- Maximum link length of 100m on OM3 Multimode Fiber (MMF) and 150m on OM4 MMF
- Single +3.3V power supply
- Real-Time Digital Diagnostic Monitoring
- Operating temperature range:0~70ºC
- RoHS compliant and lead-free
Specifications
- Part Numbers: QSFP-40G-SRBD, XVR-10066-20
- Form Factor: QSFP+
- Data Rate: 40 Gb/s
- Wavelength: 832nm – 918nm
- Fiber Type: MMF
- Max Distance: 150m@OM4 or 100m@OM3
- Optical Components: VCSEL/PIN
- Transmitter Power: -4.0 ~ +5.0dBm
- Extinction ratio: 3.5dB
- Receiver Sensitivity: <-11.0dBm
- Receiver Overload: 0.5dBm
- Connector: LC duplex
- Digital Diagnostic Monitoring: Yes
- Environment:
- Operating: 0°C to 70°C
- Storage: -40°C to 85°C
- Weight: 0.09 kg
- Application:
- Low EMI radiation Switches, servers and routers
- Telecommunication and wireless infrastructure
- Test and measurement equipment
- Networked storage systems
- Data Center networks
- Storage area networks
- Compliance:
- IEC/EN 61000-4-2,IEC-60825
- FDA 21CFR 1040.10 and 1040.11
- RoHS,SFF-8436,IEEE802.3ba
Arista
This QSFP-40G-SRBD is 100% genuine Arista product. It won't have any compatibility problem with your Arista devices. And the Arista QSFP-40G-SRBD 40GBASE-SR BD QSFP+ 850nm 150m LC DOM Transceiver Module XVR-10066-20 is factory new with original packaging. Buy it now and enjoy risk free purchase with fast worldwide delivery from GenuineModules.com
