CH21 XFP Fiber Transceiver Alcatel Lucent 10G 1560.61nm 80km DWDM FTRX-3812M321-A5
Product Details:
| Place of Origin: | Malaysia |
| Brand Name: | Alcatel-Lucent |
| Model Number: | 3HE02717AA01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiate |
| Delivery Time: | 5-8天 |
| Payment Terms: | TT, PayPal |
|
Detail Information |
|||
| DDM: | Yes | Fiber Type: | Multi-Mode/Single-Mode |
|---|---|---|---|
| Media Type: | SMF | Temperature Range: | 0°C To 70°C |
| Reach: | 80KM | Wavelength: | 1560nm |
| Transceiver Type: | DWDM | Data Rate: | 10GBase |
| High Light: | CH21 XFP Fiber Transceiver,CH21 10G XFP Transceiver,FTRX XFP Fiber Transceiver |
||
Product Description
Product Description:Alcatel Lucent 3HE02717AA 01 10G 1560.61nm 80km DWDM FTRX-3812M321-A5 CH21 XFP Fiber Transceiver
The XFP Fiber Transceiver is a high-performance, low-power transceiver with a reach of up to 80 kilometers. It has a media type of single-mode fiber (SMF) and is compliant with 10GBase data rate. The XFP Fiber Transceiver operates at a wavelength of 1560nm with a spectral range of 1530nm to 1565nm. It supports Digital Diagnostics Monitoring (DDM) and is designed for dynamic optical networking applications such as Ethernet, SONET/SDH, Fibre Channel, and OTN. This transceiver provides superior performance and reliability for 10G Ethernet and Fibre Channel applications.
Technical Parameters:
| Parameters | Values |
|---|---|
| Product Name | XFP Fiber Transceiver |
| Data Rate | 10GBase |
| Transceiver Type | DWDM |
| Connector | LC |
| Reach | 80KM |
| Fiber Type | Single-Mode |
| Media Type | SMF |
| Temperature Range | 0°C To 70°C |
| Wavelength | 1560nm |
| DDM | Yes |
Applications:
Alcatel-Lucent 3HE02717AA01 XFP Fiber Transceiver is a high performance, cost-effective module designed for 10G Ethernet, 10G Fibre Channel, and SONET. It is compliant with the XFP Multi-Source Agreement (MSA) and IEEE 802.3ae 10GBASE-LR/LW specifications. It offers excellent optical performance over a wide range of wavelengths from 1530nm to 1565nm, and with 80KM Reach. It is housed in a compact, hot-pluggable XFP module with LC connector.
This transceiver is designed for Single Mode Fiber (SMF) applications and is compliant with the extended temperature range of 0 to 70C. It is compliant with 10Gbase Ethernet and Fibre Channel applications and is suitable for high-density 10G applications.
FAQ:
A1: Alcatel-Lucent XFP Fiber Transceiver (Model Number: 3HE02717AA01) is a high-performance, cost-effective module for serial optical data communications applications. It is designed for use in 10 Gigabit Ethernet links up to 80 km in length.
A2: Alcatel-Lucent XFP Fiber Transceiver is made in Malaysia.
A3: Alcatel-Lucent XFP Fiber Transceiver supports 9/125μm Single-Mode Fiber (SMF).
A4: Alcatel-Lucent XFP Fiber Transceiver has a high bandwidth capacity, low power consumption, and supports a wide range of data rates from 622 Mbps to 10.3 Gbps.
A5: Alcatel-Lucent XFP Fiber Transceiver has a maximum transmission distance of up to 80 km.
